The E5001-OC is the orange filter cover for the Accuris SmartDoc 2.0 Imaging Enclosure (E5001-SD) — the orange-tinted operator-facing cover that provides UV / blue-light blocking for the operator's eyes while the smartphone-camera captures the gel image through a separate photo filter inside the enclosure. The E5001-OC is distinct from the E5001-ORANGE photo filter (which is the camera-side filter inserted into the smartphone platform); both are orange-tinted but serve different optical roles in the SmartDoc workflow.
Author confidence note (MEDIUM): The SmartDoc 2.0 manual references both an "orange photo filter" (E5001-ORANGE, included with the system) and a separately-priced "orange filter cover" (this E5001-OC SKU). The functional distinction is interpreted from universe label semantics: "cover" (this SKU) is the operator-facing enclosure cover with orange tint; "photo filter" (E5001-ORANGE) is the camera-side filter. Confirm exact part identity and replacement-vs-spare scope at first order.
Key Specifications
| SKU | E5001-OC |
| Type | Orange filter cover for SmartDoc 2.0 enclosure (operator-facing) |
| Compatible imaging enclosure | E5001-SD SmartDoc 2.0 (and E5001-SDB bundled package) |
| Function | Orange-tinted operator-facing cover — blocks UV / blue-light from reaching operator's eyes during gel imaging |
| Distinct from | E5001-ORANGE (camera-side orange photo filter, $32) |
| List price | $34 |
Compatibility & When to Order This SKU
Replacement orange filter cover — SmartDoc 2.0 chassis only. Order this SKU when:
- Replacement — original cover is scratched, cracked, contaminated with chemical residue, or has degraded UV-blocking / blue-light-blocking performance
- Spare-rotation for heavy-throughput labs — labs running daily SmartDoc imaging benefit from a spare cover for swap-in if the primary is being cleaned or contaminated
- Multi-chassis facilities — facilities running multiple SmartDoc 2.0 enclosures maintain spare-cover inventory for fleet maintenance
- Lost / damaged cover — replacement after equipment-relocation incidents or accidental damage during gel-handling workflows
E5001-OC vs E5001-ORANGE — What's Different
The SmartDoc 2.0 enclosure uses two orange-tinted optical components in different roles:
| Component | SKU | Role | Position in enclosure |
| Orange filter cover (this SKU) | E5001-OC ($34) | Operator-eye protection from UV / blue-light | Operator-facing — over the gel-viewing port |
| Orange photo filter | E5001-ORANGE ($32) | Camera-side excitation-light blocking | Camera platform — between the gel and the smartphone camera |
Both are orange-tinted but serve distinct optical purposes:
- The cover (E5001-OC) is the operator-safety component — keeps UV / blue light out of the operator's eyes during direct viewing
- The photo filter (E5001-ORANGE) is the camera-optical component — blocks excitation light from reaching the camera sensor while transmitting fluorescence emission
Both are included with the SmartDoc 2.0 enclosure in standard configuration; both are available as separate replacement / spare SKUs.
Application Profile
Replacement consumable for heavy-use SmartDoc enclosures — labs running daily gel-documentation workflows consume orange-cover service life faster than passive-imaging-only labs.
Spare-rotation inventory — facilities benefiting from a spare cover on hand to maintain workflow continuity during cleaning or contamination-recovery cycles.
Multi-chassis facility maintenance — sequencing cores, biotech R&D facilities, and clinical-research labs with multiple SmartDoc enclosures maintain centralized spare-cover stock.
Replacement after damage incidents — equipment-relocation or accidental-damage replacement.
Ordering & Configuration
Cleaning and maintenance. Clean with mild soap and water or 10 % bleach solution per SmartDoc cleaning recommendations. Avoid harsh detergents or organic solvents.
Pair with E5001-ORANGE if also replacing the camera-side photo filter at the same maintenance cycle.
Confirm at quote: SmartDoc 2.0 chassis (E5001-SD / E5001-SDB) in inventory, replacement vs spare-stock intent, cover quantity needed, and lead time.
Warranty: Per Accuris standard consumable terms — confirm at quote.
SmartDoc 2.0 orange-filter component pair:
- E5001-OC (this product) — Orange filter cover (operator-facing, $34)
- E5001-ORANGE — Orange photo filter (camera-side, $32)
Both ship included with the SmartDoc 2.0 enclosure; order separately for replacement or spare-quantity needs.
