12 × 15 mL Fixed-Angle Rotor for Z287-A

The Z287-1215 is the 12-position 15 mL angle rotor for the Hermle Z287-A Compact Universal Centrifuge. At 6,000 rpm / 4,427 × g across 12 × 15 mL conical or glass tubes per cycle, this rotor handles the 15 mL primary clinical-research workflow on the Z287-A chassis with angle-geometry pelleting. The 32° angle is shallower than the standard 45° microcentrifuge angle, producing a more even pellet distribution against the tube wall — appropriate for serum/plasma separation where pellet morphology matters for downstream supernatant pipetting.

Key Specifications

Compatibility & Configuration

Chassis compatibility — Z287-A only. Engineered for the Z287-A spindle and chamber geometry. RFID-tagged; chassis applies the rated 6,000 rpm cap automatically.

Direct fit for 15 mL conical and 15 mL glass. Standard Falcon-style 15 mL conical (17 mm OD × 120 mm length) and 15 mL glass research tubes (17 mm OD × 105–120 mm) fit without adapter.

Cross-rotor adapter compatibility. The Z326-prefix adapters (Z326-15-A7, Z326-15-A5) are cross-compatible — Hermle's accessory-table convention shares some adapters across chassis families.

Application Profile

12 × 15 mL clinical-research workflows on Z287-A — serum/plasma separation, cell-pellet recovery, microbiology batch culture handling at 12-tube parallel throughput.

32° angle pelleting. The shallower-than-standard angle produces a more even pellet against the tube wall — useful for clinical-research workflows where downstream supernatant pipetting needs to avoid disturbing the pellet edge.

5/7 mL Vacutainer workflows via cross-compatible adapters — when the workflow extends to smaller-volume primary collection formats.

Ordering & Configuration

12-tube symmetric loading. Opposite-pair distribution (1+7, 2+8, etc.); pre-balance pairs by weight.

Z287-1215 ships as the rotor body alone. Adapters sold separately.

Confirm Z287-A chassis pairing, adapter inventory needs, training, lead time at quote.

Warranty: 5-Year Hermle warranty (3 years full + 2 years drivetrain) on the rotor body.

Z287-A 15 mL workflow selection: the Z287-1215 (this product, 12 × 15 mL angle) is the dedicated 15 mL angle pick. For higher-RCF angle work, Z287-0815 (8 × 15 mL at 6,153 × g). For swing-out boundary clarity in the larger 50 mL format, Z287-0450H (4 × 50 mL conical swing-out).
