myGel Mini Electrophoresis System, 110 V vs myVolt Mini Power Supply, 115 V
Which should you choose?
- ▸If budget is the priority, myVolt Mini Power Supply, 115 V is the lower-cost option; myGel Mini Electrophoresis System, 110 V lists higher and typically adds capability or capacity.
Specifications side by side
| Spec | myGel Mini Electrophoresis | myVolt Mini Power |
|---|---|---|
| Fuse | 250 V, 2 A | — |
| Class | Capital — electrophoresis system | Capital — power supply |
| Timer | 0–99 min (continuous mode by setting timer to 00) | — |
| Weight | 0.45 kg (without AC transformer) | — |
| Combs A | 3 mm × 1 mm × 22 teeth / 5.6 mm × 1 mm × 12 teeth (reversible) — 2 included | — |
| Combs B | 3 mm × 1 mm × 18 teeth / 5.6 mm × 1 mm × 10 teeth (reversible) — 2 included | — |
| Voltage | 100–120 VAC (110 V model) | — |
| Dimensions | 190 × 130 × 55 mm (W × D × H) | — |
| Buffer volume | 250–300 ml (1× or 0.5× TAE / TBE standard) | — |
| Migration tank | 120 × 110 × 45 mm (inner dimension) | — |
| Output voltage | DC 35 V, DC 50 V, DC 100 V (3 selectable settings) | 100 VDC or 200 VDC (2 fixed settings, operator-selectable) |
| Casting stand A | 10.5 × 6 cm gel format (included) | — |
| Casting stand B | 5 × 6 cm gel format (included) | — |
| Gel trays included | 2 trays A (10.5 × 6 cm) + 4 trays B (5 × 6 cm) | — |
| Output jacks | — | 2 sets, wired in parallel (1 or 2 gel tanks) |
| Use restriction | — | Research only — not for medical, clinical, or diagnostic applications per brochure |
| Voltage (input) | — | 115 V |
| Air clearance requirement | — | 1 inch (2.5 cm) sides, front, rear per brochure |
Highlighted rows differ. Specs are sourced from manufacturer documentation.
FAQ
- What's the difference between the myGel Mini Electrophoresis System, 110 V and the myVolt Mini Power Supply, 115 V?
- The main differences are in Fuse, Class, Timer. The table above shows every spec side by side; the decision guide highlights which fits which use case.
- Which should I buy?
- If budget is the priority, myVolt Mini Power Supply, 115 V is the lower-cost option; myGel Mini Electrophoresis System, 110 V lists higher and typically adds capability or capacity.
- Do both carry a warranty?
- Yes, both are sold through Legacy Lab Supplies as an authorized distributor and carry full manufacturer warranty.
